ALFOplus80HDX – From 2 to 10 Gbps E-Band Full Outdoor

ALFOplus80 series is a Full-Outdoor, full IP Next Generation Millimetre wave radio operating in the E-Band (71-76 GHz / 81-86 GHz).

Whether in mobile, fixed or private networks, the E-band millimetre wave solution represents a fundamental technology tool bridging the gap between fibre high capacity systems and flexible cost effective wireless transmission. Today, our 3rd generation E-band solution, the ALFOplus80HDX, achieves 10Gbps full-duplex, ultra-high capacity and represents an even better solution acting as a prime transmission media as with fibre.

ALFOplus80HDX provides the same capacity of fibre, highest deployment flexibility and homogeneous operational behaviour as traditional microwave, allow operators to fully liaise on existing knowledge and skills, minimizing introduction costs, while modernizing the transport network.

The 3rd generation system ALFOplus80HDX is the ideal solution for ultra high capacity wireless links in urban environment for all carrier-class applications: mobile backhaul, fronthaul, enterprise, ISP.

Main Features:

• Microwave Adaptive bandwidth notification
• Up to 10 Gbps Throughput
• Channel bandwidth up to 2000 MHz
• BPSK/4/16/64/128/256 QAM modulation schemes
• Hitless Adaptive Coding Modulation and Bandwidth
• Integrated flat antenna
• AES-256 Encryption
• Power Over Ethernet
• 10 Gigabit and Gigabit interfaces
• L1 link aggregation (2+0 XPIC and Multi Band Link)
• Carrier Ethernet protocol stack
• Native SDN ready (NETCONF agent)
• SM-OS based platform
• Synchronous Ethernet and IEEE 1588v2
• Time Sync (ITU-T G.8275.1, G8273.2)
